Kohler KDW1003, 13.4 HP, 7.5 kW generator, 1800 rpm, liquid cooled diesel engine with 12 volt electric start
Fuel: Diesel
Fuel capacity: 50 US gallon (up to 100 hrs. of continuous operation) Low oil pressure, high temperature automatic shutoff, heater plug cold start system

Four-point outrigger design
Tower center-mounted between two retractable side outriggers, tongue jack, and rear jack
Remains operational in winds up to 65 mph (104.5 kph)

Frame: Formed, welded steel Adjustable height combination two inch ball coupler-three inch pintle towing hitch
Enclosure: Heavy-duty with 10-gauge side panels and 12-gauge hood
Doors: Lockable lift-up access Front panels: Color-impregnated ABS plastic Stop / Turn / Tail Lights
Forklift pockets and Tie Down Rings: standard

Lamps: 1250 watt Metal Halide SHO-HD
Models ML 6/ML 8--four fixtures
Model ML 8 available with six fixtures (1000W)

Assembly: Heavy-duty, three section tower, self-lubricating nylon rollers
Rotation: 360º rotatable from the ground

Alternator: 7.5 or 8 kw, 60 Hz, 1 phase
Model ML 7.5-7.5kw
Model ML 8-8kw
Circuits: Hard-wired electrical
Ballast: Easily serviceable, “componentized” assemblies 2-120 VAC, 1-240 VAC convenience outlets
Ground rod

Height mast lowered: 5’ 7” (1.70 m)
Height mast raised: 30’ (9.14 m)
Length without fixtures: 13’ 6” (4.11 m)
Length with fixtures: 14’ 9” (4.49 m)
Width with manual winch: 76 3/4” (195 cm)
Width with electric winch: 74” (187 cm)
Outrigger width: 12’ 10” (3.91 m)
Wheels and tires: 15” (38.1 cm)

Light fixtures: Each fixture 15 lbs. (6.75 kg), 90 lbs. (40.5 kg) for six (6)
Trailer and mast: 1960 lbs. (882 kg)
Total weight: Approx. 2080 lbs. (936 kg) with six (6) light fixtures

(all options may not be available in every configuration)

High-pressure sodium lamps and ballasts
Sound attenuation package
Saf-T-Visor™
Inside storage bracket for (4) SHO lamp fixtures (N/A with optional 70 gallon fuel tank)
Hydraulic mast (Models ML 7.5/ML 8)
Allmand LSC100 Automatic Light Sequence Commander
70 US Gallon fuel tank (up to 140 hours of continuous operation, N/A with inside lamp storage)
Kubota 1005BG liquid-cooled diesel (13.1 hp continuous) - 7.5 kW Generator
Kubota 1105BG liquid-cooled diesel (13.6 hp continuous) - 8 kW Generator
CAT C1.1 liquid-cooled diesel (14.3 hp continuous) - 8 kW Generator
